RME HDSP 9652

HDSP 9652

Overview

Connectivity

  • 3 x ADAT I/O
  • 1 x SPDIF I/O
  • 2 x MIDI I/O
  • Word Clock I/O
  • 1x ADAT Sync In
  • TotalMix
  • optional: Expansion Boards

HDSP 9652 offers 3 x ADAT optical I/O, ADAT-Sync In, SPDIF I/O and word clock I/O. On top, there are 2 MIDI I/Os and TotalMix, a DSP-based real-time mixer/router, with hardware-calculated level metering and complete MIDI remote capability.

The HDSP 9652 also supports Expansion Boards (EXB). Two internal ADAT inputs and two internal ADAT outputs allow you to realize up to 16 analog inputs, 16 analog outputs, or up to two TDIF ports directly inside the computer.

Thanks to its unique Zero CPU Load technology Hammerfall DSP guarantees highest performance and lowest latency together with full flexibility!

The HDSP 9652's Secure BIOS Technology allows to perform hardware updates via software/driver without any risk.

Top

Features

HDSP 9652

The HDSP 9652 provides unique features:

... and numerous other features found already in the Hammerfall series. And all this for an unbeatable price!

Top

Settings

Just click on the hammer symbol in the systray of the taskbar and the settings dialog of the HDSP 9652 comes up. The clear structured, easy to understand window plus the unique informative status windows for input signal, clock mode, sample rate and time code make your work with Hammerfall DSP to a real pleasure. With a simple mouse click you gain access to the full power of your card.

When working with several digital sources it is not only necessary to know if these are properly locked, but also if they are totally synchronized. RMEs exclusive SyncCheck SyncCheck
When working with several digital sources it is not only necessary that these are all properly locked, they also have to be totally synchronized. Else drop outs and crackling occurs.
RME's exclusive SyncCheck checks all input signals. In clock mode Master the synchronous operation to the internal clock is checked. This outstanding and unique technology helps to find errors immediately. The actual state of each input is displayed in the settings dialog.
® checks all input signals and displays their actual state, and thanks to our new Intelligent Clock Control (ICC) Intelligent Clock Control (ICC)
Our unique SyncCheck and AutoSync technology has evolved into the new Intelligent Clock Control of the Hammerfall DSP system. HDSP is the only digital I/O-system worldwide capable of measuring and displaying the frequency of all clock sources. Even word clock! Based on validity and current sample rate the system then decides which clock source should be used - fully automated and performed in hardware! With this the HDSP system offers the most easiest handling of the present clocks, although having a lot digital inputs, plus the most advanced support when configuring the clock setup.
  concept you have all clocks and states under control - with ease.

A display of the time code at the ADAT Sync-In port offers a quick check of the communication between external device and Hammerfall.

Top

Tech Specs

Supported sample rates: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, variable

8 buffer sizes/latencies available: 1.5 ms, 3 ms, 6 ms, 12 ms, 23 ms, 46 ms, 93 ms, 186 ms

ASIO zero CPU load technology: 0 (zero!)% CPU load when using ALL 52 channels!

All settings changeable in real-time

Clock modes slave and master

Automatic and intelligent master/slave clock control

Enhanced Mixed mode: All inputs and outputs simultaneously operational

Unsurpassed Bitclock PLL (audio synchronization) in ADAT mode

Enhanced Zero Latency Monitoring for latency-free submixes and perfect ASIO Direct Monitoring

DIGICheck, the ultimate measurement, analysis and test tool

Input 3 x optical (TOSLINK), 1 x coaxial (RCA), 2 x MIDI, word clock (BNC)

Input format SPDIF, AES/EBU (Consumer, Professional), ADAT® optical

Output 3 x optical (TOSLINK), coaxial (RCA), 2 x MIDI, word clock (BNC)

Format output SPDIF, AES/EBU (Consumer/Professional), ADAT® optical

Top

Optional Add-Ons

TEB - TDIF Expansion Board
